* Price includes GST and is ex-factory in Ballina, NSW but excludes Stamp Duty, Registration Fees, dealer delivery and on road charges.
Tare (without options and canvas choices)
3,490kg
GVM
4,100kg
Max Towable / Max GCW
2,000kg / 6,100kg
Mercedes Sprinter 419 LWB - 2.0L Bi-Turbo 9G-Tronic gears- AWD - Fitted With:• A4M 4x4 AWD with torque on demand and factory offroad lift kit• 360 degree parking camera assist • Campervan package with, upgraded axles, cockpit comfort packs • Electric sliding door • Navigation package includes 7 year map updates • Smartphone wireless charge station• Active Distance Assist - DISCTRONIC • Long Range Fuel Tank - 93L with Aux diesel take off- Factory ordered • Comfort Rotating Front Seat - Passenger side only• 10.25” High End Mercedes Infotainment Upgrade • 250A Heavy Duty Alternator • Air conditioning, semi-automatic with built in TEMPMATIC • Standard Paint - Arctic White
Standard
Comfort Rotating Front Seat & Office Desk (extra kitchen bench space) - Passenger side only
10.25" Premium Mercedes Infotainment Upgrade*
M60 - 14V 250 High Output Alternator Upgrade*
Electric Sliding Door*
Upgraded Paint - Metallic White*
Upgraded Paint - Selenite Grey or Stone Grey or custom colour
Mercedes Benz Permaguard lifetime warranty - Paint/Leather/Vinyl protection
GVM Upgrade Kit & Suspension - Federal GVM upto 4,430kg with upgraded rear suspension, remote reservoir shocks front and back and closed cell front spring dampeners
Outback Snorkel in Black - Exxonmobil polyethylene for stability & durability
KK Alloy Sports Bar with LED Light Bar on High Beam switch
Bullbar - KK ATTITUDE - Powder coat Black with LED Light bar and side LED lights - Winch Ready. Stylish and full width protection including the Ad-Blue tank
Warn Winch - 12-S Evo (5,445kg single line), 27m Synthetic Dyneema rope & IP68 rated
KK Kruz Rack roof rack backbone - Light weight alloy backbone the whole length of the roof. Can attach Aerobars, KK Solar panels at a later date.
KK Expedition Kruz Rack - Light weight alloy with Outback bright 50" LED Light Bar
x4 Corner LED Security Work Lights with Central Switching
KK Rear Swing Away for Spare Tyre & Ladder frame on rear Pax Door. Lightweight Alloy
KK Rear Swing Away for Gear Rack frame on rear Driver Door. Lightweight Alloy**
KK Rear drop bike Karrier for x2 Bikes up to 30kg each. Ezi load on and off with gas strut assistance. ** Need Rear Swing Away Gear Rack as well.
Electric Automatic Side Steps that double as rock sliders
Under Body Protection - : Engine & Gearbox Guard/Rear Diff Guard - KK Blue or burnt orange
Maxtrax x4 Pin re-enforced mount kit on side of vehicle
Maxtrax x1 Set Only
Maxtrax, mounts and Campboss Premium Recovery Gear Kit
Towbar Pack & Electrics
UHF Uniden Fitted with HighGain Antenna
Motorhome waterproof roofrack AeroPod - mounted on rear platform for ease of use.
Motorhome - Delta Gullwing Storage - Lightweight alloy rear gear box, insulated & vented for storage of gear up to 40kgs. Ideal for golf clubs ** Need Rear swing away Gear Rack as well
Current Total
Spare Tyre under Vehicle
Standard Mercedes Steel Rims and BFG A/T Offroad Tyres - 225/75 R16
KK - Alloy - Offroad Alloy wheels and AT Tyres 16"- 265/70 R16
SMART Water Storage (110L Underbody)
50L Grey Water Tank
86L Dedicated Second Tank*
80L Spare wheel well Emergency Aux Water Tank 3 - need rear wheel carrier - see dealer
Thirsty Nomad Complete Offgrid Water Purification systems - treats Bore Water too
2.2 x 4.5m HD Electric Roll Out Awning - Expedition Rack Mounted
Electric Open and Close Upgrade - Wind Out awning
Bedouin Extendable Awning
Vinyl Draft Skirt
Full Set of Canvas mesh walls for fully enclosed wind and insect free al fresco area - includes anti-flap kit
Drivers side colour coded Sailtrack & Truckmesh awning over windows on drivers side
Composite sandwich panel made from European FRP sheets and the core is a closed cell rigid extruded polystyrene. These are custom made inhouse CNC routed to precision that increases the insulation properties of the motorhome. Not only class leading U-Values for insulation properties but the closed cell eliminates leaks and water ingress and has excellent strength and a superior finish. There is no risk of rot or rust and the panels will outlast the life of the vehicle.
Motorhome hatch fan with x4 speed and suck in or out function
Inside Shower - Full size gelcoat shower with internal toilet and hard door. Large shower head with mixer- can be handheld. Extraction fan plus LED light
Shower walls colour coded to vehicle - Front/Side/Rear
Internal shower furniture - Toilet roll holder, Shower Caddy, Towel hooks, Pebble or Bamboo shower mat
Outside Hot and Cold Shower on drivers side with Visi-Flow AUX water source - allows pumping from streams and Jerry cans
Composting Toilet that separates #1’s and #2’s for up to 40 uses (OGO)
Diesel Hot Water System - German Webasto Hotwater system with "endless hotwater" ready within 5 min
Space Heater (utilises diesel hot water system)
Diesel Air Heater Ducted WITH thermostat controller 2kW rating
Pocketspring light weight Plush Mattress - Large Double (1880 x 1370)
Light weight Rooftop Airconditioner mounted near front with reverse cycle heating
Remove Rooftop Airconditioner
12V Fan with Timer Each – Can have 1x or 2x - Sirocco
Magazine Racks + SS Drink holder
Main Door and Rear Door canvas screens with Midge windows for maximum comfort.
Main table - 3 way adjustable internal table with Corian worktop
Office Desk - Lagun table that is located on inside of main door, adjustable as extra bench space, office desk or external servery
Outside "Table within a Table" - Portable table to go outside - doubles as a hidden internal table so no extra storage needed
Thermal blinds on rear windows & thermal blinds in cockpit (Kit)
Blackout ensuite curtain
Cockpit blackout curtain - Thermal backed blackout on a curtain rail for easy use
Kargo Bags with zips above front seats
Cockpit Shelf - Lightweight and lined composite shelf above front seats
Storage Pouches behind drivers side long seat
Kargo Keeper behind passengers side long seat
Kargo Organiser attached to passenger cockpit seat back
Storage Pocket at rear of passenger & driver long seat
Kargo Barrier at front & rear between passenger & driver long seat plus handbag pouch in cockpit area between driver seat and passenger seat
x5 Large opening tinted large windows for maximum airflow - insect screens and privacy screens
INSIDE: Solid Surface (Corian TM ) Benchtop, Hot and Cold Water with Stainless sink
Upgrade to a large 190L - Isotherm, dual door - Fridge (145L) and Freezer (45L) - Storage bin above
INSIDE: Smart RV - Dual Plate Induction Cooktop | Built in
INSIDE: Single Plate Induction Inside Cooktop INDUCTION (Stand Alone - Portable)
INSIDE: Microwave Oven
INSIDE: Wireless Benchtop USB Charging
Outside Kitchen: Stainless Steel Marine Hooded Gas BBQ
OUTSIDE: Cooks Kitchen - WOK Burner
OUTSIDE: Cooks Kitchen - Ninja Electric BBQ
OUTSIDE: Galley Kitchen - with portable Ninja Electric BBQ
Mercedes smart electrcial looms. Manufactured in NZ to ISO9001 standards, the electrical network is meticulously planned and professionally assembled.
Smart Touch Console- Displaying Battery capacity, voltage current, water tank levels, solar array power, Upright fridge temperature and refrigeration power used
All NEW - SMART 48V Power Hub with Control Panel - HUB includes X-Stream fast charging 3000W AC charger, 3600W AC Pure Sinwave inverter, 70Amp DC Output at 13.6V, x2 Solar regulators 1600W max and 60amp DC/DC Charger (1600W). Bluetooth and Wifi connected. Also includes SMART Monitor for total power control
5000Wh SMART 48V Battery
2nd 5000Wh SMART 48V Battery
400W Lightweight Roof Mounted Solar Panel - mounted securely on roof rack with built-in Power Hub regulator, angle mounted for self cleaning and maximum solar performance.
800W Roof Mounted Solar Panels - mounted securely on roof rack with built-in Power Hub regulator, angle mounted for self cleaning and maximum solar performance. Fly over aircon as a tropical roof for maximum thermal efficiency.
1200W Roof Mounted Solar Panels - mounted securely on roof rack with built-in Power Hub regulator, angle mounted for self cleaning and maximum solar performance. Restrictions may apply on roof options - see your Dealer for more information.
Portable 220W Ultra thin - EcoFlow Bi-Facial Technology Solar - 1600W Power Hub solar regulator - Includes 10m lead.
Dual Reading LED Stalk Lights at bed head
OUTSIDE - 2 x exterior Orange/White LED light.
OUTSIDE - Kitchen LED light - Dual Colour
Charge Points - USB-C and 12V Outlet - Outside Kitchen, End of Sink cabinet inside
INSIDE Lighting - x1 ensuite, x2 under Overheads - dimmable, x1 door entry, 1 x Pax seat work light, Mood dual strip lighting on inside of van above windows.
Under Bench LED's - underside of kitchen benches, both sides
OUTSIDE: 240V & Incoming 15Amp GPO with built-in circuit breakers
OUTSIDE - 240V double - GPO in outside kitchen
INSIDE: Double 240V GPO - End of sink/office, drivers side bench top, microwave cabinet, induction cabinet, below long seat passenger side, rear seat passenger side.
Bed Walls & Roof Lined with soft fabric or perforated automotive head liner
Drop down alloy Double Bed on KK PowerGlide lift system, one touch lift and lower with manual back up system
Total of 16 slide out alloy drawers with “sustainable” timber fronts, plus x1 cupboard unless microwave is optioned in.
x1 overhead cupboard on passenger side and x2 overhead cupboards on driver side, made from light weight alloy
Custom KK pullout out double bed step
For EcoScape Model includes an upgrade to Solid leather seating. You can also choose full face or insert.
Solid Leather SeatingChoose one colour from a selection of 27 different colours of 100% Australian hides
Leather Seating with dual hidesChoose two colours from a selection of 27 different colours of 100% Australian hides (Full face)
Internal floor Upgrade - to commercial grade imported Vinyl Floor Planks
Motorhome Interior Finish is available in two choices as standard:
Motorhome Interior Finish - "Natural"Fawn roof finish, light bench tops, sand walls, brown timber flooring
Motorhome Interior Finish - "Contemporary"Light grey roof finish, black or white bench tops, grey bed walls, slate coloured flooring
Motorhome Drawer & Door Fronts are available in three choices as standard:
Motorhome Black Paint Finish Drawer and Door Fronts
Motorhome White Paint Finish Drawer and Door Fronts
Motorhome Raw Bamboo Finish Drawer and Door Fronts
Upgraded Quality sound system with bluetooth, MP3, streaming and bluetooth. AM/FM Radio
Smart LED TV + Kimberley engineered Stainless Steel Bracket and mounting system + Swivel Knuckle Package, KK Padded Bag and External mounting
Starlink Kit for Starlink Mini - 24V DC converter for boosted power with external input jack
Starlink Kit for Starlink Gen 1, 2 and 3 - RJ45 socket into internal living area
Starlink - Permanently roof mounted Gen 3 or 4 dish in custom KK housing and hardwired modem into Kruiswagen. Super easy to use. (can supply Gen 3 dish at cost - approx $654)
TOTAL OPTIONS
*STAMP DUTY, DEALER DELIVERY & ONROADS(Please Note this is an approximate figure)
GRAND TOTAL
*Important: Viewings are by appointment only. No walk-ins will be accommodated.
